| | 品牌：青量 | | 型号：见详情 | | 加工定制：否 | |
| | 类型：枪式三爪内径千分尺 | | 测量范围：见详情 mm | | | |
枪式三爪内径千分尺
特性：
·单手操作，适用于左右使用
·三点定位，适用于盲孔和通孔的精密测量，配有接长杆可测量深孔尺寸
·硬质合金测量面，配有校对环规（100mm以上，校对环规选配），校对零位
·量表选配
·量表安装尺寸：φ8mm或φ9.525mm
|
货号
|
测量范围
|
精度
|
校对环规
|
L
|
A
|
|
305-01-000
|
6-8mm
|
0.004mm
|
φ6mm
|
50mm
|
1.5mm
|
|
305-02-000
|
8-10mm
|
0.004mm
|
φ8mm
|
50mm
|
1.5mm
|
|
305-03-000
|
10-12mm
|
0.004mm
|
φ10mm
|
50mm
|
1.5mm
|
|
305-04-000
|
12-16mm
|
0.004mm
|
φ16mm
|
65mm
|
0.5mm
|
|
305-05-000
|
16-20mm
|
0.004mm
|
φ16mm
|
65mm
|
0.5mm
|
|
305-06-000
|
20-25mm
|
0.004mm
|
φ25mm
|
91mm
|
0.5mm
|
|
305-07-000
|
25-30mm
|
0.004mm
|
φ25mm
|
91mm
|
0.5mm
|
|
305-08-000
|
30-40mm
|
0.004mm
|
φ40mm
|
97mm
|
0.5mm
|
|
305-09-000
|
40-50mm
|
0.005mm
|
φ40mm
|
97mm
|
0.5mm
|
|
305-10-000
|
50-63mm
|
0.005mm
|
φ62mm
|
112mm
|
0.5mm
|
|
305-11-000
|
62-75mm
|
0.005mm
|
φ62mm
|
112mm
|
0.5mm
|
|
305-12-000
|
75-88mm
|
0.005mm
|
φ87mm
|
112mm
|
0.5mm
|
|
305-13-000
|
87-100mm
|
0.005mm
|
φ87mm
|
112mm
|
0.5mm
|
|
305-14-000
|
100-125mm
|
0.005mm
|
φ112.5mm
|
130mm
|
0.5mm
|
|
305-15-000
|
125-150mm
|
0.005mm
|
φ137.5mm
|
130mm
|
0.5mm
|
|
305-16-000
|
150-175mm
|
0.005mm
|
φ162.5mm
|
130mm
|
0.5mm
|
|
305-17-000
|
175-200mm
|
0.005mm
|
φ187.5mm
|
130mm
|
0.5mm
|
|
305-18-000
|
200-225mm
|
0.007mm
|
φ212.5mm
|
130mm
|
0.5mm
|
|
305-19-000
|
225-250mm
|
0.007mm
|
φ237.5mm
|
130mm
|
0.5mm
|
|
305-20-000
|
250-275mm
|
0.007mm
|
φ262.5mm
|
130mm
|
0.5mm
|
|
305-21-000
|
275-300mm
|
0.007mm
|
φ287.5mm
|
130mm
|
0.5mm
|
枪式三爪内径千分尺套尺
|
货号
|
测量范围
|
单尺测量范围
|
校对环规
|
接长杆
|
|
305-44-000
|
6-12mm（A=1.5mm）
|
6-8，8-10，10-12mm
|
φ6，8，10mm
|
100mm
|
|
305-46-000
|
12-20mm（A=0.5mm）
|
12-16，16-20mm
|
φ16mm
|
150mm
|
|
305-48-000
|
20-50mm（A=0.5mm）
|
20-25，25-30，30-40，40-50mm
|
φ25，40mm
|
150mm
|
|
35-50-000
|
50-100mm（A=0.5mm）
|
50-63，62-75，75-88，87-100mm
|
φ62，87mm
|
150mm
|
